Urban BIPV Energy Visualization Platform

Communication

Regions

China

Year

2026

Award

WINNER

Affiliation

Huazhong University of Science and Technology

Designer

Chen Xi, Zhang Bingxin, Fan Yue

https://youtu.be/I5MEP7jUkWU

English

The Visualization Platform for Urban Integrated PV Planning Services is built on geographic information, presenting visualized scenarios from a global to urban and regional scale—progressing from macro to micro perspectives. By integrating meteorological data, it calculates the installed capacity, investment costs, annual power generation, and electricity cost savings for PV installations on urban building clusters, blocks, and individual buildings. The platform delivers visualized PV layout solutions, assisting governments, enterprises, and individuals in deploying building-integrated photovoltaic (BIPV) systems effectively.

Native

城市一体化光伏规划服务可视化平台以地理信息系统（GIS）为核心技术底座，深度整合空间地理数据与多维度气象资源，构建起从宏观到微观层层递进的全场景可视化体系。在全球视角下，可直观呈现光伏资源分布与光照潜力格局，为跨区域产业布局提供宏观指引；聚焦城市维度，精准还原建筑群分布、地形地貌及土地利用现状，清晰标注光伏适宜开发载体；深入区域微观场景，能细化至街区功能分区、建筑朝向及遮挡情况，实现空间信息精准呈现。平台依托多年历史气象数据与实时监测数据，通过专业算法模型，针对城市建筑群、特色街区及单栋建筑（含商业综合体、工业厂房、居民住宅等），精准测算光伏装机容量、初期投资成本，结合光照时长、辐照强度等核心参数，科学预估年发电量及全生命周期发电收益。同时联动当地电价政策，精准核算年节省电费金额与碳减排量，让经济价值与生态效益直观可见。平台以三维模型结合动态图表的可视化形式输出光伏布局方案，支持组件安装位置、倾斜角度等参数的灵活调整，为政府制定能源规划、企业筛选投资项目、个体用户安装建筑光伏提供精准数据支撑与可落地参考，高效推动建筑光伏一体化发展，助力城市能源转型与 “双碳” 目标实现。
